Glacial Lake Connecticut map

A map of Glacial Lake Connecticut.

For an upcoming book project I’ve been working with Ralph Lewis, the former Connecticut state geologist on making my LIS geology maps and figures more accurate. Lordship and Stratford Point stick out so far in the Sound because the area was a wedge (moraine and outwash river fan) between two giant ice sheet lobes, the Hudson River and Connecticut Valley lobes. Note the sharp turn in the ice edge at the Lordship – Stratford Point area. The CT Valley lobe flowed more freely, and was slower to melt back. This shows the ice edge at 20,700 calendar years ago.

Message clarity

Screen grab from Apple's web site, of the forthcoming Apple Watch.Clarity of intent and design looks simple, but requires enormous discipline, both in the messaging strategy, and the graphic design that supports it. Most companies and institutions fail at this because the easiest way to appease competing groups of stakeholders is to parse out pieces of the home page. When everybody gets a little slice of attention what you usually get is a noisy fail that is often—ironically—an accurate reflection of the muddled thinking behind the business and communication strategy. Does the world’s most valuable company look confused about its priorities, or its message?

Scrolling and “the fold” in page design

In 1994, the earliest days of the World Wide Web, human interface researcher Jakob Nielsen noted that his research showed that users of the first web browsers and web sites seemed reluctant to scroll to see portions of web pages hidden below the bottom of their display screens, and notes the importance of material at the top of web pages. Three years later Nielsen retracted his finding that “web users don’t scroll,” because his later research showed that as users adapted to the new web medium they did indeed scroll to see content on the lower parts of web pages. Unfortunately people remembered the “users don’t scroll” dictum better than the later retraction, and this mistaken meme has persisted in web design. [1, 2]

The roughly 115 square inches at the top of a home page comprise the most visible area of the web site. Most desktop or laptop users will be looking at your site on 19–22-inch monitors or on laptop screens, and the top 8–9 vertical inches (about 900–1000 pixels) are all that is sure to be visible on average screens, and perhaps less on the short but wide screens of most laptops. The measures for various mobile screens differ of course, but the basic effect is the same: the top part of the typical web page is visible, and the rest of the page is not visible unless the user scrolls. The “above the fold” metaphor refers to the middle fold in classic folded broadsheet newspapers like the New York Times or Wall Street Journal. Front-page stories “above the fold” are the most important and visible in both newspapers and web pages.

Diagram of the fold concept in web pages.

Although web users do scroll when they use the web, a number of studies have shown that there is a distinct fall-off of views in the portion of web pages that users must actively scroll to see. Eyetracking studies done by the Nielsen-Norman Group have shown that the tops of web pages get about 80% of the attention (strictly speaking, eyetracking gaze fixations on the page), and only 20% of fixations for page areas “below the fold” that they must scroll to reveal. Google conducted a study on the relative visibility of web advertisements on various page locations and also found that visibility drops off sharply at the fold, as did a similar study by Chartbeat. Significantly, the Google study also showed a drop-off in visibility “below the fold” on smaller mobile devices, but the effect was less pronounced, especially on smaller phone screen where users are used to scrolling to see page content. [3, 4, 5]

Diagrammatic summary of three research studies on scrolling and content visibility in web pages.

However, the Google and Chartbeat studies both showed that while attention and visibility do indeed drop at “the fold,” their studies found that about half of users do see material well below the fold line (~900 pixels down the page). These studies also noted something that sounds a bit counterintuitive if you assume that the top of pages are always the most visible areas: the top of the page was not the most reliably visible part of the page. Because pages are complex and often slow loading these days and users are impatient, users often begin to scroll down a page before the page top has fully rendered. Users are also well aware that the page top is commonly used for advertising, and is therefore is a less rewarding place to look for information. User attention and advertising visibility seems to peak between 500–800 pixels down the page, quite near the roughly 900 pixel fold area on most desktop and laptop screens.

Chartbeat also noticed that web readers who chose to scroll down the page often spent more time there than in the “above the fold” region, suggesting that when readers found the page content compelling that they would continue to read down the page. Taken together these studies suggest that the “the fold” is not a hard-and-fast line between great attention and no attention, that the bottom visible areas above the fold get great attention, and that the dreaded “fold line” may be less important in design than previously thought. Our own conclusions are that the fold area remains a significant transition zone, and that critical material on the page is best placed no lower than 600–700 pixels down the page to guarantee visibility on desktops and laptops.

An excerpt from the forthcoming book Web Style Guide, 4th ed., Patrick J. Lynch and Sarah Horton, to be published by Yale University Press late in 2015.

[1] Nielsen, J. 1997. Changes in Web Usability Since 1994. Nielsen-Norman, December 1, 1997.

[2] Nielsen, J. 2010. Scrolling and Attention. Nielsen-Norman, March 22, 2010.

[3] Schade, A. 2015. The Fold Manifesto: Why the Page Fold Still Matters. Nielsen-Norman, February 1, 2015.

[4] Google, 2014. The Importance of Being Seen: Viewability Insights for Digital Marketers and Publishers. Think with Google, November, 2014.

[5] Chartbeat, 2013. Scroll behavior across the web. Chartbeat Blog, August 12, 2013.

On reading and making

When you love something like reading — or drawing or music or nature — it surrounds you with a sense of connection to something great. If you are lucky enough to know this, then your search for meaning involves whatever that Something is. It’s an alchemical blend of affinity and focus that takes us to a place within that feels as close as we ever get to “home.” It’s like pulling into our own train station after a long trip — joy, relief, a pleasant exhaustion.
–Anne Lamott, Stitches

Spicy roasted carrots

Spicy roasted carrots, finished dish.
Delicious, spicy-sweet, fast and easy to make.

  • 3 cups fresh carrots, peeled and bias-sliced
  • 1 tablespoon soy sauce
  • 1 tablespoon chili oil
  • 1 teaspoon Worcestershire sauce
  • Salt and pepper to taste
  1. Peel and cut carrots, and microwave about 3 minutes, until just soft, but not fully cooked.
  2. Mix carrots with the rest of the ingredients and spread the carrot slices on a baking sheet.
  3. Broil about 15 minutes in a toaster oven, turning every 5 minutes, until brown at the edges. Watch carefully, as the carrots will brown on the bottom first.
  4. In an over, try baking at 450F, turning every 5 minutes until brown at the edges.
